Philips Senseo Switch - Page 11

HD6596/50/G /51/G
11-18
Parts list
Pos Service code Description Remark
1720 Lid spring
1730 Hose
1740 Lever Deep black
1750 Lever frame
1760 Rod (2x)
1770 Slider left
1780 Slider right
1790 Slider spring
17100 Lid frame
17110 4222 240 05991 Ejector pin
17120 4222 247 08121 Brew chamber seal
17130 4222 247 72611 Distribution disk
17140 Brewchamber bottom Black
18 4222 247 76641 Inner frame OPR
19 4222 259 70342 Main PCBA Switch OPR/IS 220 - 240 V
20 4222 247 08101 L-bend
21 4222 240 02041 Hose clamp D 9.1 mm
22 4222 259 61291 Pressure hose assy
23 4222 247 75502 Base plate Fusion black
24 4222 247 72551 Suspension bracket
25 4222 244 50693 Tie wrap Boiler
26 4222 259 37244 Pump ULKA HF 230 V
˜
50 Hz
27 4222 247 43690 Boiler pin cover
28 Hose valve assy
29 4222 247 75271 TCO cover OPR
30 4222 259 65481 Boiler assy OPR 230 V
3020 4222 247 05134 O-ring
3040 4222 259 68161 Switch NTC assy OPR
31 4222 247 08252 Hose socket
32 4213 247 05256 Foot
33 4222 247 06301 Pump damper
34 4222 247 07541 Anti vibration foam
100 4222 244 50680 Tie wrap
