HD6596/50/G /51/G
10-18
Parts list
Pos Service code Description Remark
1 4222 259 69591 Padholder assy 1-cup Crema+ Deep black
110 Padholder 1-cup
120 Co ee spout 1-cup Deep black
2 4222 259 69601 Padholder assy 2-cup Crema+ Deep black
210 Padholder 2-cup
220 Co ee spout 2-cup Deep black
3 4222 247 75762 Top collector Deep black
4 4222 240 02331 Driptray cover Metal
5 4222 247 75772 Driptray Deep black
6 4222 259 67511 Filter holder assy
610 Filter holder lid
620 Filter holder
7 4222 259 63771 Jug assy Deep black
8 9965 100 70806 Jug lid Deep black
9 4222 247 75141 Co ee spoon
10 4222 259 65932 Water container assy incl. Lid
1010 Water container lid
1020 Valve seal
1030 Valve spring
1040 Valve rod
1050 Float spring
1060 Float assy
1070 Water container Transparent
11 4222 259 60072 Check valve assy
12 4222 259 69631 Housing Beluga
13 4222 247 59473 Sensor housing
14 4222 259 69661 Top cover assy SS printed Deep black
1410 Top cover Deep black
1420 Buttons rubber
1430 Buttons plastic
1440 UI house top
1450 UI PCBA
1460 UI house bottom
15 4222 259 65892 Back plate assy Deep black
1510 WC Sealing
1520 Filter
1530 WC Socket
16 4222 247 72692 Lid cover Deep black
17 4222 259 69651 Brew chamber assy Deep black/Silver
1710 Lid hinge cover
