Figure 1 - Typical System Conguration
Figure 2 - Assemble bubble ring ass’y
Note: It is recommended to remove camera window for improving picture quality when you assemble bubble ring ass’y.
up to 255 multiplexer
Alarm Input
(up to 8)
<Sensor>
<Siren>
<Flashing light>
Alarm
Output
(up to 4)
J-box
Master keyboard
up to 3 Slave keyboards
up to 99 DVR
up to 32 cameras
push
push
remove
camera window
bubble ring ass’y
screw
Remove window Assemble bubble ring ass’y
