Philips Video Camera - Single Multiplexer

6
7
2.2.1 Single Multiplexer
Figure 5 - Single Multiplexer
Rear
Keyboard controller
Power
24VAC
BNC
Main Monitor
BNC
BNC
RS-485 (–) Pin No. 4
RS-485 (+) Pin No. 6
J-Box (Back) J-Box (Front)
AWG #24
Power
24VAC
Power
24VAC
Spot Monitor
Multiplexer
