1. Open the quick release lever. Insert the seat post into the seat
tube.
2. Adjust the height of the seat. Do not raise the seatpost
beyond the minimum insertion marking on the seat post.
3. Tighten the nut on the quick release until the lever becomes
firm to close. Close the quick release lever by your palm or
finger.
Adjusting the Seat Position and Angle
To change the angle and horizontal position of the seat:
1. Use a 6 mm Allen wrench to loosen the seat adjustment bolt
on the clamp positioned underneath the seat, above the rear
wheel. Do not remove the bolt fully.
2. Move the seat backward or forward to adjust the angle. A seat
position horizontal to flat ground is desirable for most riders.
3. While holding the seat in the desired position, use a 6 mm
allen wrench to tighten the seat angle adjustment bolt securely
to the recommended torque value.
