Swimming pool heat pump
- 45 -
F——Fan parameter
Normally, Fan will start up 5s ahead of Compressor and 30s later to shut off. When at
defrosting, Fan running situation is according to defrosting control.
F01——Fan parameter
F01=0: in low speed fan mode;
F01=1: in high speed fan mode;
F01=2: the fan running modes depend on coil or ambient temperature (F02-F07);
Attention: The temperature probe is decided by F10.
F01=3: the fan runs at low speed depends on time (F08-F09), the fan runs at high speed
during the other time;
F01=4: the fan running speed depends on F02 and F03.
F02——Coil or ambient temperature set point for high speed fan mode (Cooling)
This represents if the temperature above F02, the fan will on high speed (Cooling)
F03——Coil or ambient temperature set point for low speed fan mode (Cooling)
This represents if the temperature below which the fans remain on at low speed (Cooling)
F04——Coil or ambient temperature set point for the fan stop (Cooling)
This represents the temperature in reference to F03 below which the fans are stopped.
F05——Coil or ambient temperature set point for high speed fan mode (Heating)
This represents the temperature above which the fans remain on at high speed (Heating)
F06——Coil or ambient temperature set point for low speed fan mode (Heating)
This represents the temperature below which the fans remain on at low speed (Heating)
F07——Coil or ambient temperature set point for the fan stop (Heating)
This represents the temperature in reference to F06 below which the fans are stopped.
F08——Fan start low speed running time (Just for F01=3)
F09——Fan stop low speed running time (Just for F01=3)
F10——Fan speed control temp.
When F10=0, Fan speed is decided by coil temperature;
When F10=1, Fan speed is decided by ambient temperature.
0
0
High speed
Coil temperature (Ambient temperature)
Low speed
F02
F04
F03
The Fan speed at cooling mode
F07
F05
F06
High speed
Coil temperature（Ambient temperature）
Low speed
The Fan speed at heating mode
