PHNIX PASRW035 - Page 11

Swimming pool heat pump
- 10 -
Performance curves PASRW035
The COP curve for swimming pool (3.5P)
2.00
2.50
3.00
3.50
4.00
4.50
5.00
5.50
6.00
6.50
7.00
-7 -5 -3 -1 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31
Ambient temp.(℃)
Heating capacity / power
input(kW)
Inlet water temp.24℃ Inlet water temp.26℃ Inlet water temp.30℃
The QH curve for swimming pool (3.5P)
0.0
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
-7 -5 -3 -1 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31
Ambient temp.(℃)
ＱH
Inlet Water temp.24℃ Inlet Water temp.26℃ Inlet Water temp.30℃
