Phoenix Contact RAD-AI4-IFS User Manual

RAD-...-IFS
124 / 198
PHOENIX CONTACT 105542_en_05
ERR LED
The red ERR LED indicates the error status, e.g., if a corresponding output module has not
been found.
DI1 / DI2
The yellow DI1 and DI2 LEDs indicate the state of the digital inputs.
DO1 / DO2
The yellow DO1 and DO2 LEDs indicate the state of the digital outputs.
7.8.5 Setting the I/O MAP address
Use the thumbwheel to set the I/O MAP address. The extension module in the Radioline
wireless system is addressed using the I/O MAP address. Addresses 01 ... 99 (maximum)
can be assigned for the I/O extension modules in the entire wireless network.
7.8.6 Process data in PLC / Modbus/RTU mode
The process image of the I/O extension module consists of six data words. For additional
information, please refer to Section “RAD-DAIO6-IFS process data” on page 77.
Off No error
Flashing
Slow (1.4 Hz) I/O MAP address changed
Fast (2.8 Hz) Wireless module in I/O data mode
– Missing input module
– No bus communication
Wireless module in PLC / Modbus/RTU mode
– No Modbus communication (safe state of outputs, depending
on DIP switch setting)
On Critical internal error
Table 7-15 Setting the I/O MAP address for the RAD-DAIO6-IFS
Thumbwheel Description
01 ... 99 I/O MAP address
00 Delivery state
**, 1* ... 9* Setting not permitted
*1 ... *9 Interface system slave address, for use with other
interface system (IFS) master devices
I/O module Module type ID Register Address range Function code
RAD-DAIO6-IFS 60
hex
03
hex
(inputs)
30xx0 ... 30xx2 fc 04
03
hex
(outputs)
40xx0 ... 40xx2 fc 03, 16
