Phoenix Contact RAD-AI4-IFS - Page 162

RAD-...-IFS
162 / 198
PHOENIX CONTACT 105542_en_05
Antenna cables and adapters Typ e Order No. Pcs./Pkt.
Antenna cable for control cabinet feed-through,
outside diameter: 3.2 mm, inner conductor: flexible,
attenuation: 0.6/0.9/1.4 dB at 0.9/2.4/5.8 GHz,
connection: N (female) -> RSMA (male),
cable length: 0.5 m
RAD-PIG-EF316-N-RSMA 2701402 1
Antenna cable, outer diameter: 5 mm, inner conductor:
rigid, connection: N (male) -> RSMA (male)
Length 0.5 m,
attenuation: 0.4/0.5/0.6 dB at 0.9/2.4/5.8 GHz
Length 1 m,
attenuation: 0.5/0.8/1.1 dB at 0.9/2.4/5.8 GHz
Length 2 m,
attenuation: 0.9/1.3/2.0 dB at 0.9/2.4/5.8 GHz
Length 3 m,
attenuation: 1.2/2.0/3.0 dB at 0.9/2.4/5.8 GHz
Length 5 m,
attenuation: 2.0/3.3/4.8 dB at 0.9/2.4/5.8 GHz
RAD-PIG-RSMA/N-0.5
RAD-PIG-RSMA/N-1
RAD-PIG-RSMA/N-2
RAD-PIG-RSMA/N-3
RAD-PIG-RSMA/N-5
2903263
2903264
2903265
2903266
2702140
1
1
1
1
1
Antenna cable, outside diameter: 5 mm, inner conductor:
flexible, attenuation: 0.3/0.5/0.8 dB at 0.9/2.4/5.8 GHz,
connection: 2 x N (male), cable length: 0.5 m
FL LCX PIG-EF142-N-N 2700677 1
Attachment plug with LAMBDA/4 technology as surge
protection for coaxial signal interfaces
connection: socket-socket N connectors
For RAD-2400-IFS
For RAD-868-IFS
CN-LAMBDA/4-5.9-BB
CN-LAMBDA/4-2.2-BB
2838490
2800024
1
1
Antenna adapter for control cabinet feed-through,
frequency range: 0.3 GHz ... 6 GHz,
degree of protection: IP65, connection: 2 x N (female)
RAD-ADP-N/F-N/F 2867843 1
Antenna adapter, frequency range: 0.3 GHz ... 6 GHz,
connection: RSMA (male) -> RSMA (female), 90° angled
RAD-ADP-RSMA/M-RSMA/F-
90
2904790 1
Antenna barrier for control cabinet feed-through, type of
protection: Ex i, degree of protection: IP65, barrier instal-
lation: Zone 2, antenna installation: Zone 0, 1 or 2,
frequency range: 0.3 GHz ... 6 GHz,
connection: 2 x N (female), ATEX and IECEx approval
BAR-ANT-N-N-EX 2702198 1
Antenna splitter, frequency range: 0.3 GHz ... 6 GHz,
degree of protection: IP65, connection: 3 x N (female),
corresponding connecting cable for antenna connection
(Order No. 2700677)
RAD-SPL-2-N/N 2702293 1
