30xx1 Digital inputs
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
DI2 DI1
Terminal point
2.x 1.x
30xx2 Analog input (terminal point 3.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AI1
30xx3 ... 30xx9 Reserved
40xx1 Digital outputs
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
DO
2
DO
1
Terminal point
6.x 5.x
40xx2 Analog output (terminal point 4.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AO1
Terminal point
4.x
40xx3 ... 40xx9 Reserved
