Antenna cable - LMR195
RAD-PIG-RSMA/N-0.5 RSMA - N(m) 2903263 -0.5 dB -0.4 dB 0.5 m
RAD-PIG-RSMA/N-1 RSMA - N(m) 2903264 -0.8 dB -0.5 dB 1 m
RAD-PIG-RSMA/N-2 RSMA - N(m) 2903265 -1.3 dB -0.9 dB 2 m
RAD-PIG-RSMA/N-3 RSMA - N(m) 2903266 -2 dB -1.2 dB 3 m
RAD-PIG-RSMA/N-5 RSMA - N(m) 2702140 -3.3 dB -2 dB 5 m
Adapter
RAD-ADP-N/F-N/F N(f) - N(f) 2867843 -0.3 dB -0.3 dB -
RAD-ADP-RSMA/M-RSMA/F-90 RSMA(m) - RSMA(f),
angled 90°
2904790 -0.3 dB -0.3 dB -
Splitter
RAD-SPL-2-N/N 3 x N(f) 2702293 -0.3 dB -0.3 dB
2.4 GHz surge protection
CN-LAMBDA/4-5.9-BB N(f) - N(f) 2838490 <-0.15 dB <-0.15 dB -
868 MHz surge protection
CN-LAMBDA/4-2.2-BB N(f) - N(f) 2800024 <-0.15 dB <-0.15 dB
Antenna Connection Order
No.
Gain Remark
2.4 GHz omnidirectional antenna
RAD-ISM-2400-ANT-OMNI-2-1-
RSMA
RSMA(m) 2701362 2.1 dBi 2.1 dBi - 2.1 dB
(1.5 m cable, RG316)
RAD-ISM-2400-ANT-VAN-3-0-RSMA RSMA(m) 2701358 3 dBi 3 dBi - 1.5 dB
(1.5 m cable, EF316)
ANT-OMNI-2459-02 N(m) 2701408 2.5 dBi
RAD-ISM-2459-ANT-FOOD-6-0 N(f) 2692526 6 dBi -
RAD-ISM-2400-ANT-OMNI-6-0 N(f) 2885919 6 dBi -
RAD-ISM-2400-ANT-OMNI-9-0 N(f) 2867623 9 dBi -
868 MHz omnidirectional antenna
ANT-OMNI-868-01 N(f) 2702136 4 dBi
RAD-900-ANT-OMNI-2-N N(f) 2904802 2 dBi
2.4 GHz directional antenna
ANT-DIR-2459-01 N(f) 2701186 9 dBi -
RAD-ISM-2400-ANT-PAR-19-0 N(f) 2867885 19 dBi -
868 MHz directional antenna
ANT-DIR-868-01 N(f) 2702137 3.5 dBi
RAD-ISM-900-ANT-YAGI-6.5-N N(f) 2867814 8.5 dBi
RAD-ISM-900-ANT-YAGI-10-N N(f) 5606614 12 dBi
Adapter and cable [...] Connection [...] Order
No. [...]
Attenuation
at 2.4 GHz
Attenuation
at 868 MHz
Length
[...]
