RAD-...-IFS
152 / 198
PHOENIX CONTACT 105542_en_05
Table 9-1 Detecting and removing errors: wireless module
LED,
wireless
module
Current state and possible
cause
Solution
-
Wireless module cannot be
configured using the PSI-CONF
software.
• Make sure that the wireless module is supplied with power.
• Make sure that you are using the correct cable:
– RAD-CABLE-USB (Order No. 2903447), energy supply via the
USB port on the PC
– IFS-USB-DATACABLE (Order No. 2320500), external power
supply
• Install the USB driver. The driver is installed automatically during
PSI-CONF software installation (see page 38).
PWR off
No power supply, mains proba-
bly switched off.
• Switch on the mains, restore the power supply.
DAT off
No communication between
wireless module and
I/O extension module. Wireless
module probably in “serial data”
mode.
• Check whether the I/O extension module is properly snapped onto
the DIN rail connector and whether it is connected to the wireless
module.
• Check the operating mode of the wireless module using the
PSI-CONF software. The wireless module must be in “I/O data”,
“PLC / Modbus/RTU” mode or in dual mode (see page 38).
• Reset the wireless module to the default settings (I/O data mode), if
necessary. To do so, disconnect the device from the supply voltage,
hold down the SET button, and switch the supply voltage on again
(see page 30).
ERR on
Local bus error
The input or output module is
disconnected from the DIN rail
connector and the bus.
• Check whether the I/O extension module is properly snapped onto
the DIN rail connector.
• Press the SET button on the front of the wireless module or carry out
a power up. The data of the I/O extension modules is read again.
ERR flashing
DAT flashing
Writing to the memory stick did
not work.
• Repeat the process in order to correctly write to the memory stick.
