Phoenix Contact RAD-RS485-IFS User Manual

Technical data for the wireless modules
105542_en_05 PHOENIX CONTACT 163 / 198
Antenna cable, outer diameter: 10 mm,
inner conductor: flexible, connection: 2 x N (male)
Length 3 m,
attenuation: 1.0/1.8/3.1 dB at 0.9/2.4/5.8 GHz
Length 5 m,
attenuation: 1.6/2.9/5.0 dB at 0.9/2.4/5.8 GHz
Length 10 m,
attenuation: 2.9/5.6/9.9 dB at 0.9/2.4/5.8 GHz
Length 15 m,
attenuation: 4.3/8.3/14.8 dB at 0.9/2.4/5.8 GHz
RAD-CAB-EF393- 3M
RAD-CAB-EF393- 5M
RAD-CAB-EF393-10M
RAD-CAB-EF393-15M
2867649
2867652
2867665
2885634
1
1
1
1
Antenna adapter, frequency range: 0.3 GHz ... 6 GHz,
connection: RSMA (male) -> RSMA (female), 90° angled
RAD-ADP-RSMA/M-RSMA/F-
90
2904790 1
Antenna cables and adapters Ty pe Order No. Pcs./Pkt.
Energy supply Ty pe Order No. Pcs./Pkt.
Solar system for worldwide use, consisting of a solar
panel, prewired control cabinet with charge controller,
solar batteries, fuses, surge protection, and mounting
material (including mast clips)
24 V / 100 Wp
24 V / 200 Wp
RAD-SOL-SET-24-100
RAD-SOL-SET-24-200
2885472
2917722
1
1
DIN rail power supply unit, primary-switched,
narrow design, output: 24 V DC/1.5 A
MINI-SYS-PS-100-
240AC/24DC/1.5
2866983 1
Control box Ty pe Order No. Pcs./Pkt.
Control box for robust setup of wireless systems for indus-
trial applications, IP65, 25 x 18 x 13 cm, polycarbonate
material, gray, drilled, including DIN rail, plugs, and screw
connections, without devices
FL RUGGED BOX 2701204 1
