Phoenix Contact RAD-RS485-IFS User Manual

Technical data for the wireless modules
105542_en_05 PHOENIX CONTACT 165 / 198
Wireless interface RAD-2400-IFS... RAD-868-IFS
Antenna connection method RSMA (female)
Direction Bidirectional
Frequency 2.4 GHz 868 MHz
Frequency range 2.4002 GHz ... 2.4785 GHz 869.4 MHz ... 869.65 MHz
Number of channel groups 8 14
Number of channels per group 55 -
Channel distance 1.3 MHz 30 kHz
(depending on the network
structure and data transmis-
sion rate)
Data transmission rate (adjustable) 16 kbps
125 kbps
250 kbps
1.2 kbps
9.6 kbps
19.2 kbps
60 kbps
120 kbps
Receiver sensitivity -106.00 dBm (16 kbps)
-96.00 dBm (125 kbps)
-93.00 dBm (250 kbps)
-122 dBm (1.2 kbps)
-114 dBm (9.6 kbps)
-111 dBm (19.2 kbps)
-104 dBm (60 kbps)
-103 dBm (120 kbps)
Transmission power ≤20 dBm (outside Europe, can
be set via software)
≤19 dBm (Europe, can be set
via software, depends on the
data rate)
≤18 dBm (default setting)
≤27 dBm (default setting, can
be set)
Security 128-bit data encryption
Operating mode I/O data (default setting, configuration via thumbwheel)
serial data, PLC / Modbus/RTU mode,
PLC / Modbus/RTU dual mode
(activation and configuration via PSI-CONF software)
RS-232 interface
Connection method COMBICON plug-in screw terminal block
Connection technology 3-wire
Data rate 0.3 kbps ... 115.2 kbps
Transmission length ≤15 m
RS-485 interface
Connection method COMBICON plug-in screw terminal block
Connection technology 2-wire
Data rate 0.3 kbps ... 187.5 kbps
Transmission length ≤1200 m
Termination resistor (can be switched on via DIP
switches)
390 Ω / 150 Ω / 390 Ω
