Typical combinations of antennas and adapter cables
105542_en_05 PHOENIX CONTACT 183 / 198
Item Product Description Connection Order No.
1 IP54 stainless steel housing - -
2Power supply --
3 RAD-2400-IFS or RAD-868-IFS wireless module and I/O extension modules - -
4
RAD-PIG-RSMA/N-0.5 Antenna cable, 0.5 m length, 50 Ω impedance N (male)
RSMA (male)
2903263
Alternative:
RAD-PIG-RSMA/N-1 Antenna cable, 1 m length
N (male)
RSMA (male)
2903264
RAD-PIG-RSMA/N-2 Antenna cable, 2 m length 2903265
RAD-PIG-RSMA/N-3 Antenna cable, 3 m length 2903266
RAD-PIG-RSMA/N-5 Antenna cable, 5 m length 2702140
5
BAR-ANT-N-N-EX Antenna barrier for control cabinet feed-
through, type of protection: Ex i, degree of
protection: IP65, barrier installation: Zone 2,
antenna installation: Zone 0, 1 or 2,
frequency range: 0.3 GHz ... 6 GHz,
ATEX and IECEx approval
N (female)
N (female)
2702198
6
RAD-CAB-EF393- 3M Antenna cable, 3 m length, 50 Ω impedance N (male)
N (male)
2867649
Alternative:
RAD-CAB-EF393- 5M Antenna cable, 5 m length
N (male)
N (male)
2867652
RAD-CAB-EF393-10M Antenna cable, 10 m length 2867665
RAD-CAB-EF393-15M Antenna cable, 15 m length 2885634
7
ANT-DIR-2459-01 Directional antenna, 2.4 GHz/5 GHz, gain:
9 dBi, polarization: linear, opening angle: h/v
75°/55°, degree of protection: IP67, seawater-
resistant, including mounting bracket and mast
clips, ATEX and IECEx approval
N (female) 2701186
Alternative:
RAD-ISM-2400-ANT-OMNI-6-0 Omnidirectional antenna, 2.4 GHz, gain: 6 dBi,
polarization: linear, opening angle: h/v 360°/30°,
degree of protection: IP67, seawater-resistant,
including mounting bracket and mast clips,
ATEX and IECEx approval
N (female)
2885919
ANT-DIR-868-01 Directional antenna, 868 MHz, gain: 3.5 dBi,
polarization: circular, opening angle: h/v 135°/90°,
degree of protection: IP67, seawater-resistant,
including mounting bracket and mast clips,
ATEX and IECEx approval
2702137
ANT-OMNI-868-01 Omnidirectional antenna, 868 MHz, gain:
4 dBi, polarization: linear, opening angle: h/v
360°/30°, degree of protection: IP67, seawa-
ter-resistant, including mounting bracket and
mast clips, ATEX and IECEx approval
2702136
