Phoenix Contact RAD-RS485-IFS User Manual

PLC / Modbus/RTU
105542_en_05 PHOENIX CONTACT 71 / 198
6.6.3 RAD-AO4-IFS process data
I/O module Module type ID Register Address range Function code
RAD-AO4-IFS 30
hex
06
hex
40xx0 ... 40xx5
1
1
xx = I/O MAP address set using the white thumbwheel
fc 03, 16
Table 6-11 RAD-AO4-IFS module type and timeliness of data
40xx0
1
1
xx = I/O MAP address set using the white thumbwheel
Module type and timeliness of data
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Y
2
2
Y = timeliness of data, bit 8
If the data in the register is not up to date, then the register value is 1. If the process data has been written
to one of the registers, then the register value is 0. The register value then remains 0 for the entire operat-
ing time of the device.
Module type
3
3
If the module type in the register is invalid or not available, then the register value is 0.
40xx1 Reserved
40xx2 Analog output 1 (terminal point 2.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AO1
40xx3 Analog output 2 (terminal point 3.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AO2
40xx4 Analog output 3 (terminal point 4.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AO3
40xx5 Analog output 4 (terminal point 5.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AO4
40xx6 ... 40xx9 Reserved
