Phoenix Model BULLDOG - Installing the Aileron Servo and Linkages (High Wing)

Instruction Manual BULLDOG
16 17 18
19 20
21 22 23
24 25 26
27 28 29
Installing the aileron servo and linkages (high wing):
2
3
Mark the rear of the servo box onto the wing. Glue the servo box onto the wing.
Install the connector rod to the control horn.
Prepare the linkages as these picture above. Prepare the linkages as these picture above. Prepare the linkages as these picture above.
Glue the carbon rod using the C.A glue.
Remove the covering from the aileron
servo box.
Remove the covering.
Remove the covering.
Remove the covering from rear of the
servo box.
Tape the servo lead into the end of the thread.Using the thread and the collar as a guide. Install the aileron servo.
