12 OF 12 PCS300 SERIES INSTALLATION GUIDE 650-321-017 08/16 ©2014 Phoenix Controls Specifications subject to change without notice. Rev. C
2.10 Phoenix Controls Cables
Cable
Ty p e
Plenum
Rated
Function
Wire
Gauge
Primary
Vendor/Part #
Alternate Vendor/
Part #
Color Code Notes
2C Round No 24 Vac power 18 Belden 9409 1: Red
2: Black
Must be stranded
24 Vac power 14 Belden 9411
2C Round Yes 24 Vac power 18 Belden 82740 Windy City
NP002360
1: Red
2: Black
Must be stranded
24 Vac power 14 Windy City NP007960
TP NO FTT-10 (4,500 FT)
TP1250 (425 FT)
22 Windy City 107500
www,smartwire.com
1: White with Blue Stripe
2: Blue with White Stripe
FTT-10 (8,000 FT) 16 Windy City 109600
www,smartwire.com
TP Yes FTT-10 (4,500 FT)
TP1250 (425 FT)
22 Windy City 105500
S=SPOOL B=BOX
1: White with Blue Stripe
2: Blue with White Stripe
FTT-10 (8,000 FT) 16 Windy City 109500
www,smartwire.com
3C Round No Signal 22 Belden 8443 1: Red
2: Black
3: Green
Must be stranded
3C or 4C
Round
Yes Signal 22 Belden 88444 Windy City 004380 1: Red
2: Black
3: Green
4: White (not used as 3C)
Must be stranded
4C Round No Signal 22 Belden 8444 Manhattan M13304 1: White
2: Green
3: Black
4: Red
Must be stranded
5C Round No Signal 22 Belden 8445 Manhattan M13305 1: White
2: Brown
3: Black
4: Red
5: Green
Must be stranded
8C No Signal 22 Belden 9421 Manhattan M13308 1: White
2: Orange
3: Black
4: Red
5: Green
6: Yellow
7: Blue
8: Brown
No substitutes
8C Yes Signal 22 Comtran 4956 1: White
2: Orange
3: Black
4: Red
5: Green
6: Yellow
7: Blue
8: Brown
No substitutes
3C
MS/TP
No Shielded 22 Belden 3106A
(120 ohm)
1: White with Orange stripe
2: Orange with White stripe
3: Blue with White stripe
Shielded with
drain
3C
MS/TP
Yes Shielded 22 Connect-Air W223C-
2060YPC
1: Black
2: White
3: Red
Foil shield with
drain wire
Phoenix and Phoenix Controls are trademarks of Honeywell International, Inc.
The material in this document is for information purposes only and is subject to change without notice. Phoenix Controls assumes no responsibility for any errors
or for consequential damages that may result from the use or misrepresentation of any of the material in this publication.
Phoenix Controls is a business of Honeywell International, Inc.
For additional information and a listing of our global offices, please visit our Web site at www.phoenixcontrols.com or call (800) 340-0007.
