4. Step-by-step instructions for using
the Phonak PilotOne remote control
Step 1. Inserting or replacing the battery
Slide the battery cover in the direction of the arrow to
remove it (Fig. 1a).
If necessary remove the old battery first. Insert 1 new
battery with the correct +/– position
(Alkaline 1.5 V, type AAA, LR03 or AM4), (Fig. 1b).
Secure the battery cover by sliding it in the direction
of the arrow (Fig. 1c).
The mini-USB port cannot be used for battery
charging. Do not use rechargeable batteries.
Fig. 1a Fig. 1b Fig. 1c
