Phonic AM440DP - SPECIFICATIONS

5
AM440DP
English
SPECIFICATIONS
Model Name AM 440DP
Inputs
Total Channels 6
Balanced Mono Mic / Line Channel 4
Balanced Stereo Line Channel 2
Outputs
Main L/R Stereo 2 x 1/4” TRS, Bal.
Rec Out Stereo RCA
Phones 1
Channel Strips 6
EFX Send 1
Pan/Balance Control Yes
Volume Controls Rotary
Master Section
Phones Level Control Yes
Main L/R Level Control Main L/R, 60mm fader
Level Meter 2 x 4-segment
Phantom Power Supply +48VDC
USB Playback MP3 & WMA
Maximum Playback Bitrate 320 kbit/second
Frequency Response (Mic input to any output)
20Hz ~ 60KHz +0/-1 dB
20Hz ~ 100KHz +0/-3 dB
Crosstalk (1KHz @ 0dBu, 20Hz to 20KHz bandwidth, channel in to main L/R outputs)
Channel fader down, other channels at unity <-90 dB
Noise (20Hz~20KHz; measured at main output, Channels 1-4 unit gain;EQ at; all channels on main mix; channels 1/3 as far left as
possible, channels 2/4 as far right as possible.
Reference=+6dBu)
Master @ unity, channel fader down -86.5 dBu
Master @ unity, channel fader @ unity -84 dBu
S/N ratio, ref to +4 >90 dB
Microphone Preamp E.I.N. (150 ohms terminated, max gain) <-129.5 dBm
THD (Any output, 1KHz @ +14dBu, 20Hz to 20KHz, channel inputs) <0.005%
CMRR (1 KHz @ -60dBu, Gain at maximum) 80 dB
Maximum Level
Mic Preamp Input +10 dBu
All Other Input +22 dBu
Balanced Output +28 dBu
Impedance
Mic Preamp Input 2 K ohms
All Other Input (except insert) 10 K ohms
RCA 2T Output 1.1 K ohms
Equalization 3-band, +/-15 dB
Low EQ 80 Hz
Mid EQ 2.5 KHz
Hi EQ 12 KHz
Low Cut Filter 75Hz (-18dB/oct)
Effect Processor 100 effects with tap delay control
Power Requirement (external power supply, depends on region) 100VAC, 120VAC, 220~240VAC, 50/60Hz
Weight 1.72 kg (3.78 lbs)
Dimensions (WxHxD) 242 x 55 x 225mm (9.5” x 2.16” x 8.86”)
