AM5GE / AM6GE
English
9
Crosstalk (1KHz @ 0dBu, 20Hz to 20KHz bandwidth, channel in to main L/R outputs)
Channel fader down, other channels at
unity
<-90 dB <-90 dB
Noise (20Hz to 20KHz; measured at main output, Channels 1-4 unit gain; EQ at; all channels on main mix;
channels 1/3 as far left as possible, channels 2/4 as far right as possible. Reference=+6dBu)
Master @ unity, channel fader down -86.5 dBu -86.5 dBu
Master @ unity, channel fader @ unity -84 dBu -84 dBu
S/N ratio, ref to +4 >90 dB >90 dB
Microphone Preamp E.I.N. (150
ohms terminated, max gain)
<-129.5 dBm <-129.5 dBm
THD (Any output, 1KHz @ +14dBu,
20Hz to 20KHz, channel inputs)
<0.005% <0.005%
CMRR (1 KHz @ -60dBu, Gain at
max.)
80 dB 80 dB
Maximum Level
Mic Preamp Input +10 dBu +10 dBu
All Other Input +22 dBu +22 dBu
Balanced Output +28 dBu +28 dBu
Impedance
Mic Preamp Input 2 K ohms 2 K ohms
All Other Input (except insert) 10 K ohms 10 K ohms
RCA 2T Output 1.1 K ohms 1.1 K ohms
Equalization
2-band, +/ -15 dB
(mono only)
2-band, +/-15 dB
(3-band on Stereo Ch)
Low EQ 80 Hz 80 Hz
Mid EQ - 2.5 KHz (stereo ch)
Hi EQ 12 KHz 12 KHz
Power Requirement (depends on
region)
5V - 20V DC (USB) 5V - 20V DC (USB)
Dimensions (W x H x D)
155.6 x 50.5 x 244 mm
(6.12" x 1.99" x 8.82")
190 x 56 x 233 mm
(7.48" x 2.2" x 9.17")
Weight 1.1 kg (2.4 lbs) 1.5 kg (3.3 lbs)
