9MU1202 / MU1202X
Impedance
Mic Preamp Input 2 K ohms 2 K ohms
All Other Input (except insert) 10 K ohms 10 K ohms
RCA 2T Output 1.1 K ohms 1.1 K ohms
Equalization 3-band, +/-15 dB 3-band, +/-15 dB
Low EQ 80 Hz 80 Hz
Mid EQ 2.5 KHz 2.5 KHz
Hi EQ 12 KHz 12 KHz
Low Cut Filter 75Hz (-18dB/oct) 75Hz (-18dB/oct)
Effect Processor N/A
16 effects with one main
parameter control
Power Requirement (external power
supply, depends on region)
100VAC, 120VAC,
220~240VAC, 50/60Hz
100VAC, 120VAC,
220~240VAC, 50/60Hz
Weight 2.2kg (4.85 lbs) 2.6 kg (5.73)
Dimensions (WxHxD)
275 x 60 x 271mm
(10.8” x 2.4” x 10.7”)
245 x 86 x 271mm
(9.7” x 3.4” x 10.7”)
