Phonic POWERPOD 620 plus v1 User Manual

Phonic Part No. Specications Ref.
23
POWERPOD 620 V1
PL US
01A305001020G M/C 0.001uF J 50V 5T P C60
030000000800G CHOCK COIL TF5104 XIANYI L3.4
01F336002220G M.P/C 0.0022uF J 63V T
C61
01F00H101030G M.P/C 0.01uF K 400V NONINDUCTIVE C57
030100003800G
COIL L 100uH L5
01F336001030G M.P/C 0.01uF J 63V T(SQUARE PP) C62.64
060000000500G DIODE UF4007 D22.23
01F336003920G MP/C 0.0039uF J 63V (SQUARE) T C63
061011123000G Z/DIODE 12V J 1W ZD7
060000001100G DIODE P6KE200A ZD1.2
0610A1473000G Z/DIODE 47V 0.5W 1N5261B
ZD6
060000001300G DIODE H16C40C MOSPEC D17
0610A2183000G Z/DIODE 18V K 0.5W FAIRCH ZD4.5
062000000100G DIODE 1N4148 D13
060000001500G DIODE H16C40A MOSPEC D18
070000000500G TRN 2N5551 TO-92-D BRAIDED Q23
060000001700G DIODE HER308 D14.20
072000000700G TRF 2SK30A GR TO-92-D (TO) Q24
0D02001S0220G EMX1850S POWER PCB CEM-1
.
060000004300G DIODE P6KE150A ZD3
066000000100G B/DIODE PB154 XULI BD10
000103710020G CF RES. 10K J 0.25W T R94.95.98,R98,R94.95.98
066000000400G B/DIODE PBU805 ZHUYI BD9
01A308001020G M/C 0.001uF J 100V 5T P C76B
070100003900G TRN MJE340 SOT32-D(ON/MO) Q22
072000002100G TRF IRG4PC50W TO-247-D(IR) Q21
080000010500G IC UC3842BN MINIDIP U9
09A010000000G TMP/SW TB02B 100 DEGREE C B TYPE
TH1
0AA000230000G 2P WAFER/S 5267 A2505 WV JPP5
0AA100462600G 4P WAFER/P 380MM UL1015#18 CNN2
0AA101031000G 10P WAFER/P UL1007#26 380MM
0G901M000100G HEAT SINK 56.8*40*40 EMX1850S
0G9069000100G HEAT SINK(B) 15*10.7*40mm
0J2000V00000G TEMPERATURE SWITCH FIXED 8*23.6*2.8
0L0430101000G M/E PAN SCR. M3.0*10 NI D=5.5
0L0530061000G M/E SET SCR. M3.0*6 NI
0L1530062000G T/P SET SCR. M3.0*6 BLK
0N0000000000G TRANSISTOR WASHER TO-220 SHENGSH-
ENG
0N0000007100G WASHER TO-3P
0N1000008000G GND LUG PC250 KANGYANG 17-836-01
GND
POWER PCB-PART LIST(10202001T020G)

Phonic POWERPOD 620 plus v1 Specifications

General

Brand	Phonic
Model	POWERPOD 620 plus v1
Category	Mixer
Language	English
