Phonic POWERPOD 620 plus v1 User Manual

Phonic Part No. Specications Ref.
25
POWERPOD 620 V1
PL US
DSP PCB-PART LIST(10202000Y040G)
007200710020G CHIP RES. 10K J 0603
WITH ON/OFF AND,FOOT
SW WELD,R39;WITH ON,/
OFF&FOOT,SW WELD R40
007200700000G CHIP RES. 0 J 0603 R65.118.64,119
014332201060G MINI E/C 10uF M 16V T D3*H5 C1.35.38,28-30.47,50.56
007200710000G CHIP RES. 100 J 0603 R38
014335201050G MINI E/C 1uF M 50V T C19
007200710010G CHIP RES. 1K J 0603 R5.34.79,97.103
0A0002470000G 24P B.E./S SOCKET PH:1.27 SMD FEMALE CN4
007200710020G CHIP RES. 10K J 0603
R3.4.6.24,31-33.43,45-
48.54,50-52.55,72.112.117,
104-107.,128.130,132.134,135.
137,139.36.37,126.82.100
0ND001620100G
CRYSTAL INSULATION BUSHES OA-6
YONGZHEN
Y3.4
007200710030G CHIP RES. 100K J 0603 R59
0NH016004100G CRYSTAL 16MHZ HC-49US XINGU Y4
007200720080G CHIP RES. 2 J 0603 R76
0NH020004100G CRYSTAL 20MHz 49S Y3
10002000Y040G PM3000 DSP PCB SMD
007200722010G CHIP RES. 2K2 J 0603 R67
007200733070G CHIP RES. 33 J 0603
R1.2.7-
12,15.18.20.,22.23.25,28-
30.42,44.49.61,
66.69.116,121.122
007200747020G CHIP RES. 47K J 0603 R35
007200762070G CHIP RES. 62 J 0603 R56
007210712000G CHIP RES. 120 J 0805 R68
016465001000G CHIP C/C 10PF J 50V 0603 X7R C26.27
016465001010G CHIP C/C 100PF J 50V 0603 X7R C3
016465002000G CHIP C/C 20P J 50V 0603 X7R C39.40
030100000A00G BEAD COIL 0805 L1.2
071100002100G TRP BC856B SOT-23-M (PHI) Q1.2
080100003100G IC LD1117S33TR SOT-223-M REEL U8
080101010800G IC LM1117S-ADJ/TR SOT223 U3
084100000A5TG MCU MSP430F1471IPM QFP-64(TI)
U1
084100000B00G DSP TMS320VC5501PGF300 U2
085100000A00G IC IS42S16100C1-7TL TSOP ICSI
U6
087100000A00G IC TLV320AIC23BPW(TI)
U10
0D02000Y0400G PM3000 DSP PCB FR4 1/1
