PI 2 Design PI2AES - Operating Specifications; PI2 AES Operating Specifications

PI2Media PI2AES Hardware Reference Manual – P0.1 - 3/27/2019
PAGE 4
2
22
2 OPERATING
OPERATING OPERATING
OPERATING S
SS
SPECIFICATIONS
PECIFICATIONSPECIFICATIONS
PECIFICATIONS
2.1 PI2AES OPERATING SPECIFICATIONS
The PI2AES conforms to the following specifications:
Specification Value
Dimensions 85mm x 56.5mm
Weight ~10g
Storage Temperature -20C to +85C
Operating Temperature 0C to +70C
Humidity 0% to 95% RH, Non-Condensing
Input Voltage (VIN) +12V to +48V
Power Consumption 250mw Typical, 1W Maximum
Table 1 – PI2AES Operating Specifications
