pi-top [4] Robotics Kit | Alex Build Instructions
Use the 2mm Hex
Key to tighten
Encoder motors
Part 1
Encoder Motor
x2
Wheel Connector
and Grub Screw
x2
2mm Hex Key
x2
Make sure you align
the at edge of the
motor correctly to the
Wheel Connector
x2
