pi-top [4] Robotics Kit | Alex Build Instructions
Build guide
a. Rear Bumper ........................................................ 9
b. Chassis ................................................................ 11
c. Castor Wheel...................................................... 12
d. Side Bumpers ..................................................... 13
e. Front Bumper .....................................................16
f. Expansion Plate ................................................. 19
g. Encoder Motors ................................................. 20
i. Wheels.................................................................. 23
j. Servo motors .......................................................24
k. Camera ................................................................ 27
l. Ultrasonic Sensor ............................................... 28
m. pi-top [4] ............................................................29
Connecting cables ................................................ 30
m
f
a
b
d
d
h
c
g
i
k
e
j
l
