-2-
PKI-0007-3
● Thislampisahangingtypeandusesabracket.Ifusingitupright,setthebracketupcorrectlysothatthePIAAlogois
properlydisplayed.
●
Inorderforthelamptoperformatitsfullpotential,userelayharnessesmanufacturedbyPIAA.
●
Allworkproceduresshouldbecarriedoutinalocationwithadequatespace.Placetheshiftleverinneutralorinthep
arking
position.Turnofftheengineandsetthesidebrake.
●
Makesuretheenginecompartmentisadequatelycoolbeforestartingwork.Donotbeginworkifenginepartssuchasradiator
,
oil-coolerorturbopartarestillhot.
Beextremelycarefulwhenhandlingthelampandtheswitchharness.Ifdroppedorexcessiveshockisappliedtothelens,
thebulbortheswitchharness,itmaycauseirreversibledamage.
●
Donotaddadditionalholestothemainbodyofthelamp.Also,donotapplyadhesivesorstickerstothelampparts.
●
Donotmodifythelampharnessortheswitchharnessinanyway.Suchmodificationsmaycauseittooverheatorshort.Insome
cases,itmaycausethevehicletocatchfire.PIAAwillnotbeliablefordamagecausedbysuchmodifications.
●
Whenremovingthebatteryterminals,donottouchthe(-)and(+)terminalssimultaneously.Anelectricalshockmayoccur.
Wearrubbergloveswhencarryingoutsuchworkprocedures.
●
Makesurethe(-)and(+)terminalsdonotmakecontactwithmetal.Itcanbeextremelydangerousifashortoccurs.
●
Makesureallboltsaretightlysecure.Ifthereareanylooseboltstightenthemaccordingly.
●
Afterinstallingthelamp,adjustthelampsothebeamshinesatleast40minfrontofthevehicle.Also,adjustthelampal
ittle
towardtheleftsothatitdoesnotshinedirectlyintotheeyesoftheopposingdriverofavehicle.(astrafficlawsstipul
ate-
refertop.8foradjustmentprocedures)
●
Afterinstallingthelamp,makesuretheheadlamps,wipersandhornareworkingnormally.
●
Whenthebatteryterminalisremoved,memoryrelatedtotheclo
ck,radio,audiosystemetc,willbeaffected.Afterallwork
proceduresarecompleted,resettotheoriginalsettings.(Foradjustmentproceduresrefertoyourcarʼ sinstructionmanual)
Pleasereadtheinstallationproceduresthoroughlybeforehand.
● Beforeyoubeginalwaysremovethe(-)and(+)terminals.
Alwaysremovethe(-)terminalfirstandmakesureashortdoesnotoccur.
●
Whenremovingthebatteryterminals,alwaysturnthekeytoOFFandremoveit.T
urnallotherelectricalunitsoffsuchas
thelightswitch.
●
Whenremovingthebatteryterminals,ifacord(foranelectricalunit)isconnected,windalengthofvinyltapearo
undthe
(-)and(+)terminalstoclearlyidentifythem.
●
Verifythe(+)terminal(white)andearth(black)beforeconnecting.
●
Donotobtain(+)voltagefromthealternator.
●
Obtainthe(+)currentnecessaryfortheswitchfromthe(+)
currentusedforthelightswitch.
(Donotusethesamecurrentusedforacomputer,radiooraudiosystem)
●
Installtheswitchharnessinapositionwhereitwillnotmakecontactwithhightemperaturesurfacessuchastheengine,
radiatororenginecompartment.
●
Arrangetheswitchharnesssothatitdoesnotmakecontactwithmovingparts.
●
Donotplacetheswitchharnessonhigh-voltagewiressuchasbrakeorair-conditioningwires.
●
Iftheswitchharnessmakescontactwithapartoftheengine,applyalengthofordinarycushionedtapearoundtheharness.
●
Whenconnectingtheconnector,insertuntilyouhearanaudible“click”
●
Whenremovingtheconnector,holdthemainbodyoftheconnectorandpullitout.Ifex
cessforceisusedtopullthecord,it
maydamagetheconnection,whichcouldcauseittooverheat.
●
Makesuretheharnessdoesnotsag.Useaharnessbandofvinyltapetosecureitinplacetowiringinsidetheenginecompartment.
●
Beforeconnectingittothebattery,verifythewiringarrangement.
●
Whenconnectingthebatteryterminalandorotherelectricalunits,donotmistakethe(-)and(+)terminals.Alwaysstartw
ith
the(+)terminal.
●
Afterallwiringiscomplete,confirmthatitworksproperly.Ifitfailstoactivate,referto “【4】Troubleshooting”
section
ofthismanual.
●
Whendoingwiringwork,strictlyfollowthecautionarypoints
mentionedbelow.Incorrectorfaultywiringmaycausethelamp
tooperateimproperly.Insomecases,itmaycausethevehicletocatchfire.
CautionRegardingWiring/Pleasereadthoroughly
