Piaa LP530 - Product Details; Tools Required; Lamp Installation Preparations and Temporary Setup

-3-
PKI-0007-3
※ Pleaseusethetoolsindicatedbelow.
● Phillipsheaddriver
※ Verifyallthepartsareincluded.Ifapartismissing,pleasecontactyourlocaldistributor.
ProductDetails
switch
● Tape ● Pliers
ToolsRequired
① Lampmainunit(2units) ② Switchharnessset
[1set]
④
One-touchconnector(1pc)
⑤ Wiretie(5pcs)
③
Double-sticktape(2pcs)
● Electricdrill ● File● Holesaw( φ 20mm)
● Usingtheholesinthelampbracket,theheightfromthelampbodytotheinstallationsurfacecanbe
adjusted.Dependingonthetopandbottommeasurementsaswellasshape.
● Incasethemountingsurfaceisnotflatpositionorisnotenoughspaceofitʼ ssurface,pleasemake
suretofixthelampstablybyusingdouble-sticktapeandscrews(sellseparately).
【1】Lampinstallationpreparationsandtemporarysetup
Type Ａ
91mm
74mm
100mm
74mm
Mountingthatcombinesbracketandlamp
TypeB
