01_01
Dashboard (01_01)
A = Ignition key-switch
B = Starter button
C = Throttle control
D = Front brake lever
E = Cooling hatch
F = Turn signal switch
G = Light switch with passing
H = Rear brake control
I = Horn button
L = Switch pre-installation
M = Bag hook
N = Saddle opening electric switch
O = Switch pre-installation
PI = Engine cut-off switch
Q = Instrument panel
01_02
Analogue instrument panel (01_02)
A = Speedometer (km/h)
B = Odometer
C = Trip odometer
D = Oil pressure warning light
E = High-beam warning light
