Seat
•
To remove the saddle, loosen the three
screws shown in the figure.
Side fairings
- Remove side bumpers by removing the mounting
screws shown in the figure (one on each side).
Rear rack
- Loosen the two mounting screws and remove the
battery cover.
Remove the plastic cover of the rear luggage rack
by removing the two side screws from the lower
side of the rack.
- Loosen the 3 hexagonal retaining screws indica-
ted in the figure and remove luggage rack.
Beverly 500 i.e. Chassis
CHAS - 311
