2.3 bar
03_07
03_08
Spark plug dismantlement (03_07, 03_08)
Remove cover «A» after unscrewing the corresponding screws Detach the spark plug
shielded cap and remove the plug with the box-spanner supplied. When refitting the
plug, tighten it manually, being sure to insert it at the right angle; Use the wrench only
to fasten it. Carefully reinsert the screening hood. To reassemble the cover follow the
steps in reverse order, making sure to insert the pin in the upper part of the central
cover.
CAUTION
FOLLOW THESE PROCEDURES VERY CAREFULLY TO AVOID ANY SEVERE
DAMAGE THAT MAY BE CAUSED BY THE VERY POWERFUL IGNITION SYS-
TEM.
CAUTION
THE SPARK PLUG MUST BE REMOVED WHEN THE ENGINE IS COLD.
USING IGNITION ELECTRONIC CENTRAL UNITS OR SPARK PLUGS OTHER
THAN THE TYPES PRESCRIBED (SEE «TECHNICAL DATA» SECTION) CAN
CAUSE SERIOUS DAMAGE TO THE ENGINE.
Characteristic
Spark plug
NGK CR 8EB
Alternative spark plug
32
