Rear-view mirrors (03_25)
The mirrors can be set to the desired position by adjusting the mirror frame.
03_25
To remove the rear-view mirror rotate the rear-view mirror support rod clockwise.
03_26
Idle adjustment (03_26, 03_27)
Proceed as follows:
1. Rest the vehicle on its centre-stand and lift the seat (as described in the "Lifting the
seat & helmet compartment" section).
2. Loosen the fixing screws «A» and remove the carburettor access door.
3. Start the engine, hence tighten or loosen the idle adjusting screw «B» until the
prescribed idle speed is reached and the rear wheel is not spinning.
If any problems arise during this operation, please contact your PIAGGIO Dealer or
Authorised Service Station to perform a CO check at idle.
WARNING
IDLE SPEED MUST BE ADJUSTED WHEN THE ENGINE IS VERY HOT. BEFORE
THIS OPERATION, MAKE SURE THAT THE THROTTLE GRIP HAS THE RECOM-
44
