PIAGGIO Fly 50 4T User Manual

03_23
Front direction indicators (03_23)
In order to replace the front turn indicator bulbs remove the light taking off the retaining
screws, then remove the bulb holder form its support; gently turn the bulb around 30º
and remove it. Follow the process in reverse order to refit.
03_24
Rear optical unit (03_24)
To access the rear taillight bulb it is necessary to remove the 2 fixing screws «D».
Doing so it is possible to access also the turn indicator bulbs. Gently push and turn
the bulb about 30° and then remove it. To refit follow the same steps but in reverse
order.
N.B.
IF MISTING IS NOTICED ON THE INSIDE OF THE HEADLAMP GLASS, THIS
DOES NOT INDICATE A FAULT AND IS ATTRIBUTABLE TO HUMIDITY AND/OR
TO LOW TEMPERATURES.
THE PHENOMENON SHOULD QUICKLY DISAPPEAR WHEN THE LIGHT IS
SWITCHED ON.
THE PRESENCE OF DROPS OF WATER, ON THE OTHER HAND, COULD INDI-
CATE THAT WATER IS INFILTRATING. CONTACT THE AFTER-SALES SERVICE
NETWORK.
43
3 Maintenance

PIAGGIO Fly 50 4T Specifications

General

Displacement	49.9 cc
Fuel System	Carburetor
Fuel Capacity	6.5 liters
Front Suspension	Telescopic hydraulic fork
Rear Suspension	Single hydraulic shock absorber
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70 - 12"
Rear Tire	120/70 - 12"
Width	735 mm
Seat Height	760 mm
Dry Weight	96 kg
Engine Type	Single-cylinder, 4-stroke
Cooling System	Air-cooled
Transmission	Automatic
