01_21
Press the saddle opening button and lift the saddle.
01_22
Opening the saddle to access the helmet compartment in an
emergency (01_22, 01_23)
If there is no battery power supply, proceed as following:
- Put the ignition switch to «OFF» and press it to open the front case hatch.
01_23
- Pull the lever located inside the case to the top to open the saddle.
19
1 Vehicle

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the PIAGGIO Liberty 50IE 2019 and is the answer not in the manual?

PIAGGIO Liberty 50IE 2019 Specifications

General IconGeneral
Displacement49.9 cc
Fuel SystemElectronic Fuel Injection
TransmissionAutomatic CVT
Seat Height780 mm
Brakes (Front)Disc
Brakes (Rear)Drum
Wheelbase1, 340 mm
CoolingAir-cooled
Front SuspensionTelescopic fork
Width700 mm
Rear SuspensionSingle shock absorber
Front Tire90/80-16
Rear Tire100/80-14
Engine TypeSingle-cylinder, 4-stroke
