03_39
Helmet compartment lighting bulb (03_39)
Open the rear boot and insert a small plain slot screwdriver in the lateral notch to
detach the snap-on glass "D", then replace the bulb.
03_40
Rear-view mirrors (03_40)
The mirrors can be set to the desired position by adjusting the mirror frame.
03_41
Idle adjustment (03_41)
Proceed as follows:
1. Rest the scooter on its centre stand and lift the saddle.
2. Remove the access door to the carburettor.
3. To adjust the idle speed, start the engine, then loosen or tighten the screw indicated
in the figure until you reach the recommended idle speed taking care the engine does
not make the rear wheel move.
If it is difficult to adjust the idle speed, take your vehicle to an Authorised PIAGGIO
Service Centre or Dealer.
74
