PIAGGIO MP3 250 i.e. - Page 63

Protected circuits:Battery-
powered saddle opening switch,
glove-box lighting, headlight,
emergency turn indicator
Location:battery compartment
Fuse No. 5 Capacity: 15 A
Protected circuits:Battery-
powered injection loads, electrical
fan
Location:battery compartment
Fuse No. 6 Capacity: 3A
Protected circuits:Battery-
powered injection control unit
Location:battery compartment
Fuse No. 7 Capacity: 7.5 A
Protected circuits:Battery-
powered instrument panel
Location:footrest
Fuse No. 8 Capacity: 10A
Protected circuits:Live stop and
start lights
Location:footrest
Fuse No. 9 Capacity: 7.5 A
Protected circuits:live passing
and horn
63
