housing with forced air circulation
cooling.
Lubrication Engine lubrication with lobe pump
(inside crankcase) controlled by a
chain with double filter: mesh and
paper.
Cooling Forced fluid circulation, with
engine driven pump; 3-way
thermostat to pump intake.
Front suspension The tilt mechanism is composed of
an articulated parallelogram
suspension with die-cast
aluminium control arms and two
side headstocks plus shock
absorbers with hydraulic locking
system.
Rear suspension Single arm with two double-acting
hydraulic shock absorbers and
preloading adjustable to 4
positions.
Front wheel Alloy rims: 12" x 3.00"
Rear wheel Alloy rim: 12"x 3.50"
Front tyre Without inner tube 120/70-12" 51P
Rear tyre Without inner tube: 130/70-12" 62P
Front brake Ø 240 mm double disk with
hydraulic control activated by the
handlebar right-hand lever.
Rear brake Ø 240 mm disc brake with
hydraulic control activated by the
handlebar left-side lever.
Chassis Tubular and sheet steel.
83
