VEHICLE TECHNICAL DATA
Chassis Tubular and sheet steel
Front suspension The tilt mechanism is composed of
an articulated parallelogram
suspension with die-cast
aluminium control arms and two
side headstocks plus shock
absorbers with hydraulic locking
system.
Rear suspension Two double-acting shock
absorbers, adjustable to four
positions at preloading.
Front brake Ø 240 mm double disk with
hydraulic control activated by the
handlebar right-hand lever.
Rear brake disc brake, diameter 240 mm, with
hydraulic servo operated from the
handlebar with the left-hand lever.
Wheel rim type Light alloy rims.
Front rim 12'' x 3.00
Rear rim 14'' x 4.50
Front tyre Tubeless 120/70-12" 51S or 51P
Rear tyre Tubeless 140/70 - 14" 68S or 68P
reinf
Front tyre pressure (with
passenger)
1.6 bar (1.8 bar)
Rear tyre pressure (with
passenger)
2.4 bar (2.6 bar)
82
