Kerb weight 253 ± 5 kg
Maximum weight allowed 445 kg
Battery 12 V / 14 Ah, SEALED BATTERY
DATI VEICOLO
Chassis Tubular and sheet steel
Front suspension The tilt mechanism is composed of
an articulated parallelogram
suspension with die-cast
aluminium control arms and two
side headstocks plus shock
absorbers with hydraulic locking
system.
Rear suspension Two double-acting shock
absorbers, adjustable to four
positions at preloading.
Front brake 240 mm dia. disc brake with
hydraulic control activated from
handlebar with right lever
Rear brake Ø 240 mm disc brake with
hydraulic control activated by the
handlebar left-side lever.
Wheel rim type Light alloy rims.
Front rim 12'' x 3.00
Rear rim 14'' x 4.50
Front tyre Tubeless 120/70-12" 51S or 51P
Rear tyre Tubeless 140/70 - 14" 68S or 68P
reinf
83
