Front suspension Double effect hydraulic telescopic
fork with Ø 35 mm stems and pin
backwards with connections for
double brake calliper
Rear suspension Engine with swinging fork attached
to the frame by means of an arm
with one degree of freedom and a
pair of double effect hydraulic
shock absorbers with 4 adjustable
preload positions.
Front brake Ø 240mm double disk brake with
hydraulic control activated by the
handlebar right-hand lever.
Rear brake Ø 240 mm disc brake with
hydraulic control activated by
handlebar left lever.
Front wheel rim Die-cast aluminium alloy,
3.50"x14''
Rear wheel rim Die-cast aluminium alloy 4.50"x14"
Front tyre Tubeless 120/70 - 14'' - Michelin
Gold Standard M/C 55S
Rear tyre Tubeless 140/70 - 14'' - Michelin
Gold Standard M/C 68S
Frame Welded tubular steel structure,
with asymmetrical frame structure,
front beams and union elements in
stamped sheets.
Kerb weight 206 kg
Maximum load 180 kg.
Cooling system Capacity: approx. 1.8 litres
82
