AirCube 02 038206 000 200 is intended for use in the electromagnetic environment specied below. Customers or users of
AirCube 02 038206 000 200 must ensure that it is used in the recommended environment.
Emissions test Complies Electromagnetic environment - guide
RF emissions CISPR 11 Group 1
AirCube 02 038206 000 200 uses RF energy only for its
internal operation. Therefore, its RF emissions are very low and it
is very unlikely that they interfere with nearby electronic devices
RF emissions CISPR 11 Class B
AirCube 02 038206 000 200 is suitable for use in every
room or domestic environment, and in rooms directly connected
to a low voltage public network powering buildings used for
domestic purposes
Harmonic current emissions IEC
61000-3-2
Class A
Voltage Fluctuations and Flicker IEC
61000-3-3
Compliant
Immunity test IEC 60601 test level Level of compliance
Electromagnetic
environment - guide
Electrostatic discharge (ESD) IEC
61000-4-2
In contact ± 6 kV
In air ± 8 kV
In contact ± 6 kV
In air ± 8 kV
Floors should be wood,
concrete or ceramic tile.
If the floors are covered
with synthetic material, the
relative humidity should be
at least 30%.
Electrical fast transient/burst IEC
61000-4-4
± 2 kV for power lines ± 2 kV for power lines
The quality of the network
voltage must be equivalent
to that of a typical
commercial or hospital
setting.
Surge IEC 61000-4-5 ± 1 kV between phases ± 1 kV between phases
Voltage dips, short interruptions
and voltage variations IEC
61000-4-11
<5 % U
T
(>95 % dip in U
T
) for
0.5 cycles
40 % U
T
(60 % dip in U
T
) for
5 cycles
70 % U
T
(30 % dip in U
T
) for
25 cycles
<5 % U
T
(>95 % dip in U
T
) for 5 s
<5 % U
T
(>95 % dip in U
T
) for
0.5 cycles
40 % U
T
(60 % dip in U
T
) for
5 cycles
70 % U
T
(30 % dip in U
T
) for
25 cycles
<5 % U
T
(>95 % dip in U
T
) for 5 s
Power frequency magnetic eld
(50/60 Hz) IEC 61000-4-8
3 A/m 3 A/m
Electromagnetic elds at
network frequency must
have levels equivalent to
those of a typical commercial
or hospital setting.
NB: U
T
is the network AC voltage before applying the test level.
Conducted disturbances,
induced by radio-frequency
elds IEC 61000-4-6
Radiated radio-frequency IEC
61000-4-3
3 V e from 150 kHz to 80 MHz
3 V/m from 80 MHz to 2.5 GHz
V
1
=3 V e from 150 kHz to
80 MHz
E
1
= 3 V/m from 80 MHz to
2.5 GHz
Portable and mobile RF com-
munication devices must not
be used closer to any part of
the AirCube 02 038206
000 200, including the
cables, than the separation
distance calculated by the
equation applicable to the
transmitter frequency.
d = [3.5 / V
1
] √ P
d = [3.5 / E
1
] √ P from 80
MHz to 800MHz
d = [7 / E
1
] √ P from 800
MHz to 2.5 GHz
Where P is the maximum
rated output
power of the transmitter in
Watts (W) according to the
transmitter manufacturer
and d is the recommended
separation distance in
metres (m). The intensities
of the elds from xed RF
transmitters, as determined
in an electromagnetic study
of the site
a)
,
may be less than the
level of conformity of each
frequency interval
b)
.
Interference may occur
near devices marked by the
following symbol:
NOTE 1 - At 80 MHz and 800 MHz, the distance for the highest frequency range is to be applied.
NOTE 2 - These guidelines may not cover all situations. Electromagnetic radiation is affected by absorption and reflection by
structures, objects and people.
a)
The eld intensities for xed transmitters like base stations for radio telephones (cellular and cordless) and terrestrial mobile radios,
HAM radio devices, AM and FM radio transmitters and TV transmitters can not be theoretically foreseen accurately. In order to
assess an electromagnetic environment caused by xed RF transmitters an electromagnetic study of the site must be considered.
If the eld intensity measured in the location where the AirCube 02 038206 000 200 is used exceeds the applicable level of
conformity above the normal operation of the AirCube 02 038206 000 200 must be placed under observation. If abnormal
performance is noted additional measures may required such as different orientation or positioning of the AirCube 02 038206
000 200.
b
The eld intensity in 150 kHz to 80 MHz frequency range must be less than [V
1
] V/m.
