PROGRAMMABLE POTENTIOMETER MODULE 40-296
pickering
SECTION 7 - MAINTENANCE INFORMATION
Table 7.9 - Calibration Test Results For 40-296 (24-Bit Versions)
Serial Number:
Channel Number:
Date of Test:
Operator’s Name:
Test Equipment Used:
Resistance
Setting
Nominal
Value
Measured
Value
Maximum
Value
Minimum
Value
Result
(delete as
appropriate)
PATH 0Ω See Note1
See Note1 Pass / Fail
R1 1Ω 0.955Ω
0.795Ω Pass / Fail
R2 2Ω 1.96Ω
1.79Ω Pass / Fail
R3 4Ω 3.97Ω
3.78Ω Pass / Fail
R4 8Ω 7.99Ω
7.76Ω Pass / Fail
R5 16Ω 16.03Ω
15.72Ω Pass / Fail
R6 32Ω 32.11Ω
31.64Ω Pass / Fail
R7 64Ω 64.27Ω
63.48Ω Pass / Fail
R8 128Ω 128.6Ω
127.2Ω Pass / Fail
R9 256Ω 257.2Ω
254.5Ω Pass / Fail
R10 512Ω 514.5Ω
509.2Ω Pass / Fail
R11 1024Ω 1029.1Ω
1018.7Ω Pass / Fail
R12 2048Ω 2058.2Ω
2037.6Ω Pass / Fail
R13 4096Ω 4116Ω
4075Ω Pass / Fail
R14 8192Ω 8233Ω
8151Ω Pass / Fail
R15 16384Ω 16466Ω
16302Ω Pass / Fail
R16 32768Ω 32932Ω
32604Ω Pass / Fail
R17 65536Ω 65864Ω
65208Ω Pass / Fail
R18 131072Ω 132383Ω
129761Ω Pass / Fail
R19 262144Ω 264765Ω
259522Ω Pass / Fail
R20 524288Ω 529531Ω
519045Ω Pass / Fail
R21 1048576Ω 1059062Ω
1038090Ω Pass / Fail
R22 2097152Ω 2118123Ω
2076180Ω Pass / Fail
R23 4194304Ω 4236247Ω
4152361Ω Pass / Fail
R24 8388608Ω 8472494Ω
8304722Ω Pass / Fail
Note 1: PATH resistance limits are 1.5Ω to 6Ω.
Note 2: All results in colour are taken with the DMM offset to remove the PATH result form the answer.
