Piega P Sub 4 - Page 11

11
This is a widely used conguration for stereo mode, although it is not recommended for surround mode since there is a risk of
overloading with small satellite loudspeakers. With this conguration, the connection is made to the amplier. Refer to the appropriate
manual for information about operation and connection options for your power amplier.
PIEGA P SUB 4
Conguration example for stereo mode
Subwoofer mode via loudspeaker terminals
Connecting the System
Connection:
>Connect the P SUB 4 MKII cable to the amplier terminal
marked SPEAKER (or similar)
>Likewise connect up the loudspeakers (parallel) to the terminal
marked SPEAKER (or similar)
>For this use two similar connection cables (not supplied)
Benet:
Frequently used conguration in stereo mode
>Flexible positioning of components...!
HI LEVEL INPUT
Front
Speaker R
Front
Speaker L
Amplifier
