PN 350-007660-07 P a g e | 11
Troubleshooting
The display is not illuminated
Check the power connections to the LCD monitor
and the electrical outlet
The force is not changing on the LCD monitor
when clamp pressure is applied
Check the load cell assembly connection at the
LCD monitor
Erroneous readings on the LCD monitor (i.e. -50)
Connect the load cell cable to the LCD monitor
The force reading on the LCD monitor is fluctuating
excessively
Allow up to 24 hour equilibrium time prior to
initial use after connecting to the electrical outlet
The force reading on the LCD monitor is not
showing zero despite no clamp force being applied
Adjust the force reading to zero using the zero
adjust screw located on the right side of the LCD
monitor
Service and Repairs
For service and repairs, please contact PIKE Technologies, Inc. to obtain a Returned Merchandise
Authorization (RMA) number. When submitting a load cell assembly or LCD display for service, both
parts must be sent together.
Replacement Parts
Part Number Description
025-3092 Concave Press Tip for High-Pressure Clamp (MIRacle or GladiATR)
025-3093 Swivel Press Tip for High-Pressure Clamp (MIRacle or GladiATR)
025-3094 7.8 ATR Press Tip (Three Reflection MIRacle plate)
025-3095 Flat Press Tip for High-Pressure Clamp (MIRacle or GladiATR)
Notes
The Digital Force Adapter may be fitted to the High-Pressure Clamp of the MIRacle, GladiATR. It is not
compatible with the MIRacle micrometer clamp. Due to the sensitivity to temperature of the load cell
assembly, it is not recommended for heated ATR accessories.
