A
RH SIMILAR
LH SHOWN
A
A
FUEL TANK
DRAIN RESERVOIR
DRAIN
VALVE
ICN-PC24-A-A15000000-A-S4080-07831-A-001-01
Figure 2-3-5: Fuel - Drain Water
Section 2 - Aircraft Servicing
Ground Servicing Guide Report No: 02484
Issue date: Apr 29, 2020
Page 2-3-9
PC24-A-A15-12-0011-00A-211A-A
