Pilatus PC-9 - Control Surface Adjustments & CG; Rudder Adjustment; Elevator Adjustment; Center of Gravity (CG)

TP Screw (2.3x12mm)
1.5mm
3mm
Rod (2x300mm)
Clevis
Washer(3x15mm)
Washer
Lock Nut (3mm )
Screw (3x35mm)
Screw (2x10mm)
4
2
Wooden Block(20x20x8mm)
Servo tray(68.5x56.5x2mm)
8
TP Screw (2.3x12mm)
1
Rib template (2mm ply)
4
Wood dowel (6x30mm)
Main wing joiner
2
Fix the flap servo to the servo tray with epoxy.
TP Screw (2.3x12mm)
8
TP Screw (2.3x12mm)
Assemble the flap servo to the main wing with screws.
1.5mm
According to the rib template drill holes in the outer
wings and epoxy wood dowel in them.
6mm
Rib template (2mm ply)
Main wing joiner
Wood dowel (6x30mm)
4
Wood dowel (6x30mm)
1
Rib template (2mm ply)
Main wing joiner
2
According to the rib template drill holes to the center wing.
6mm
Rib template (2mm ply)
Main wing joiner
Secure the servo.Install the nylon control horn and
connect the linkage.
Accessory list for the coming installation steps.
6
7
9
8
2
10
ELEVATOR
Side View
25mm
25mm
Top view
Position for
right diagram.
Never fly before checking CG’s required position.
In order to obtain the CG specified reposition the
receiver and battery.
Right view
Side View
30mm
30mm
RUDDER
The centre of the Gravity.
110mm
Adjustment of the elevator to make sure they can
work perfectly.
Adjustment of the rudder to make sure it can
work perfectly.
15
77
76
75
