Chapter 3 Measuring Parameters
3.1 Voltage
PBAT61 could measure the real-time voltage of VRLA battery cell. The
measuring range of PBAT61-2 is from DC 1.6~2.6V , and PBAT61-12 is form
DC 7.5~15.6V.
3.2 Internal resistance
PBAT61 could measure the internal resistance of VRLA battery cell. The
measuring range of PBAT61 is from 0.1 to 100mΩ.
Note: The interval between two internal resistance measurements should
not be less than two minutes, otherwise the sensor will be damaged because of
overheat.
3.2 Negative pole temperature
PBAT61 could measure the negative pole temperature of VRLA battery cell
with the range from -20°C~+85°C.
