Pilot Communications PBAT-61 User Manual

11
Chapter 7 Technical Specifications
Dimension
Main-body：65mm（L）×65mm（W）×28.8mm（H）
Power
Supply
PBAT61-2 rated voltage is DC 2V with the range from DC 1.6 to DC 2.6V.
Power loss：200mW(working mode)/12mW(sleep mode)
PBAT61-12 rated voltage is DC 12Vwith the range from DC 7.5V～15.6V
Power loss：125mW(working mode)/10mW(sleep mode)
Item
Range
Accuracy
Note
Voltage
2V battery：1.6V~2.6V
12V battery：7.5V~15.6V
±0.2%
Resolution：
0.001V
Resistance
2V battery：0.1~100mΩ
12V battery：0.1~100mΩ
Consistency：
±(1.5%+25μΩ)
Repeatability：
±(1.0%+25μΩ)
Resolution：
0.001mΩ
Item
Test Conditions
Insulation
Insulation voltage:DC1000V, Insulation resistance>550MΩ
Dielectric
strength
Test voltage AC 3750V, Test time 1minute, leakage current< 1mA
Impulse
withstand
voltage
Test voltage 6kV, 1.2/50us, ± 3 times each

Pilot Communications PBAT-61 Specifications

General

Brand	Pilot Communications
Model	PBAT-61
Category	Accessories
Language	English
