Pilot Communications SPM93 - Page 21

18
Item
LCD display
Remark
MODBUS
address
MODBUS address, range:
1~247, default 1
MODBUS
baud rate
MODBUS baud rate, range:
9600, 4800, 2400,1200 default
9600bps
CT ratio
CT ratio is the ratio of current
primary and secondary. Range
1~1000, default 1.
When select 5(6)A model, should
connect with external CT.
Connection
mode
Fixed to 3 phase 4 wire
Pulse
constant
63A:Pulse output constant,
default 400
5A:Pulse output constant, default
6400
